Antik SmartHotel- GRMS
GRMS - Guest Room Management System
With ANTIK guest room management system (GRMS) hotel is able to manage different scenario in each guest room. Lighting, temperature or curtains are controlled by guest with touch panel situated in room or centrally by the hotel. System provides the key to efficiently and centrally manage guestroom energy consumption, gives more comfort, higher security to the room and easy maintenance system.
Central unit
- Display type: color LED
- Resolution: 128 x 128/1:1 aspect ratio
- Visible area: 26 x 26 mm
- Maximum number of units: max. 32 units to one BUS line
- Communication speed: 100 Mbps
- Supply voltage/tolerance: 27 V DC, -20/+10%
- Dimensions: 90 x 105 x 65 mm
Glass card holder
- Switching voltage: 230 V AC or 30 V DC
- Operating temperature: -20 - +55°C
- Supports RFID media with a carrier frequeny of 13.56 MHz
- Supported card types: MIFARE, Ultralight, DESFire, 2K, Plus S 4K
- Equipped with an 8A relay output and an AgSnO2 contact
- Designed for mounting into an installation box.
- Dimensions: 142 x 94 x 36 mm
With Antik GRMS you are able to bring guests comfort to another level. Lighting, temperature or curtains are controlled by guest with touch panel situated in the room or centrally by the hotel. Thanks to seamless integration to TV system same features can be controlled via TV remote control. System provides the key to efficiently and centrally manage guestroom energy consumption, gives more comfort, higher security to the room and easy maintenance system.
Touch Screen With Display
- Supply voltage/tolerance: 27 V DC, -20/+10 %
- Aspect ratio: 3:4
- Visible area: 52,5 x 70 mm
- Backlight: active
- Touchpad: 4-wire resistive
- Display 3,5´´
- Dimensions: 94 x 94 x 36 mm
Glass Switch Panel
- Number of control buttons: 10
- Temperature measuring: YES, built-in temperature sensor
- Resolution: by setting 10-bit
- Installation BUS: BUS
- Supply voltage/tolerance: 27 V DC, -20/+10 %
- Dimensions: 142 x 94 x 36 mm
